详细参数
| 参数名称 | 参数值 |
| Source Content uid | ADP150AUJZ-2.8-R7 |
| Brand Name | Analog Devices Inc |
| 是否无铅 | 含铅 |
| 是否Rohs认证 | 符合 |
| 生命周期 | Active |
| Objectid | 1646060974 |
| 零件包装代码 | TSOT |
| 包装说明 | VSSOP, TSOP5/6,.11,37 |
| 针数 | 5 |
| 制造商包装代码 | UJ-5 |
| Reach Compliance Code | compliant |
| Country Of Origin | Mainland China |
| ECCN代码 | EAR99 |
| HTS代码 | 8542.39.00.01 |
| 风险等级 | 1.61 |
| Samacsys Description | Linear Voltage Regulators 150mA Ultra-Low Noise LDO 2.8 Vout |
| Samacsys Manufacturer | Analog Devices |
| Samacsys Modified On | 2020-05-21 07:13:14 |
| YTEOL | 8.5 |
| 可调性 | FIXED |
| 最大回动电压 1 | 0.16 V |
| 标称回动电压 1 | 0.105 V |
| 最大绝对输入电压 | 6.5 V |
| 最大输入电压 | 5.5 V |
| 最小输入电压 | 2.2 V |
| JESD-30 代码 | R-PDSO-G5 |
| JESD-609代码 | e3 |
| 长度 | 2.9 mm |
| 最大电网调整率 | 0.0032% |
| 最大负载调整率 | 0.0315% |
| 湿度敏感等级 | 1 |
| 功能数量 | 1 |
| 输出次数 | 1 |
| 端子数量 | 5 |
| 工作温度TJ-Max | 125 °C |
| 工作温度TJ-Min | -40 °C |
| 最大输出电流 1 | 0.15 A |
| 最大输出电压 1 | 2.842 V |
| 最小输出电压 1 | 2.73 V |
| 标称输出电压 1 | 2.8 V |
| 封装主体材料 | PLASTIC/EPOXY |
| 封装代码 | VSSOP |
| 封装等效代码 | TSOP5/6,.11,37 |
| 封装形状 | RECTANGULAR |
| 封装形式 | SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH |
| 包装方法 | TR |
| 峰值回流温度（摄氏度） | 260 |
| 认证状态 | Not Qualified |
| 调节器类型 | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR |
| 座面最大高度 | 1 mm |
| 子类别 | Other Regulators |
| 表面贴装 | YES |
| 技术 | CMOS |
| 端子面层 | MATTE TIN |
| 端子形式 | GULL WING |
| 端子节距 | 0.95 mm |
| 端子位置 | DUAL |
| 处于峰值回流温度下的最长时间 | 30 |
| 最大电压容差 | 2.5% |
| 宽度 | 1.6 mm |
